GV-AS Bridge

Description

GV-AS Bridge is a cloud controller that bridges GV-AS Controller and GV-DFK1355 readers to the cloud-based GV-Cloud Access Control for integrated monitoring and administration. It also serves as a controller for storing access data and transmits the data to GV-Cloud Access Control for central access management. A maximum of 8 readers can be either directly connected or connected via GV-AS Controller to GV-AS Bridge. Up to 4 doors access administration is applicable at a time for the access control. Using GV-AS Bridge, you can transmit the data collected from the connected GV-AS Controller and GV-Reader to GV-Cloud Access Control for various applications, including access logs, central management for different surveillance sites, user management, and access rule settings.

When directly connecting to IP cameras or connecting IP cameras using the GV-Cloud Bridge encoder, GV-AS Bridge can transmit snapshots, live view, and playback recordings to GV-Cloud Access Control upon access events. Up to 4 IP cameras can be directly connected to GV-AS Bridge or via a single GV-Cloud Bridge.

Compatible Products:

  • GV-AS Controller : GV-AS210 / 2110 / 2120, GV-AS410 / 4110 / 4111 firmware V2.60 or later
  • GV-Reader : GV-DFK1355
  • GV-Cloud Access Control (cloud-based software) : V1.00 or later
  • GV-Cloud VMS (cloud-based software) : V1.00 or later
  • GV-Cloud Bridge (encoder) : firmware V1.03 or later
  • Camera : GV-IP cameras and ONVIF cameras

Key Features

  • Up to 8 readers connection via GV-AS Controller
  • Up to 8 RS-485 GV-Reader connection (GV-DFK1355)
  • Up to 4-door access control
  • Access logs and event images upload onto GV-Cloud Access Control
  • Live view display of connected IP cameras on GV-Cloud Access Control
  • Stores up to 100,000 cards

Note: Specifications are subject to change without notice.

Overview





Note: Specifications are subject to change without notice.

Accessories

Model No Name Details
GV-PA191 PoE Adapter GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable.
GV-POE Switch GV-POE Switch is designed to provide power along with network connection to IP devices. It is available in various models with different numbers and types of ports.
Power Adapter Contact our sales representatives for the countries and areas supported.

Packing List

  • GV-AS Bridge
  • Terminal Block
  • Download Guide

Note: Specifications are subject to change without notice.

Download

https://www.geovision.com.tw/download/product/GV-AS%20Bridge
