GV-IP Decoder Box Optimal

Description

GV-IP Decoder Box Optimal is designed to decode and display up to 64 IP videos in a single, 4-division, 6-division, 8-division, and 9-division view. It supports third-party IP cameras that adhere to RTSP or ONVIF, and can automatically search for any ONVIF-compliant on the same LAN. With HDMI and VGA output ports, dual monitor display is made accessible, allowing the live view of cameras to loop on the extended screen for a more effective surveillance environment. The security administrator can monitor channels, take snapshots of critical moments, and pause a channel when events occur. GV-Joystick V2 can be installed to control any PTZ / Speed Dome cameras connected onto the GV-IP Decoder Box Optimal.


The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Key Features

  • Decode video streams in H. 264 / H.265 codec up to 30 fps
  • Decode up to 8 megapixel IP cameras
  • Decode up to 64 IP streams
  • Auto-search for ONVIF IP devices
  • Support for third-party IP cameras that adhere to RTSP or ONVIF
  • Single, 4-divsion, 6-division, 8-division, and 9-division view
  • Display of Matrix view through GV-Mobile Server
  • Support for 10/100 Ethernet over LAN
  • DC 12V / PoE (IEEE 802.3af)
  • Dual monitor display for HDMI / VGA output
  • User interface controls using GV-IR Remote Control
  • PTZ and Speed Dome camera controls using GV-Joystick V2
  • Remote firmware upgrade, IP address configuration and addition of new channel
  • Micro SD card and USB drive for snapshot storage and firmware upgrade

Note:

  • Specifications are subject to change without notice.

Overview


Note:

  • Specifications are subject to change without notice.

Accessories

Model No Name Details
Wall Mount Kit Use the Wall Mount Kit to install your GV-IP Decoder Box on wall.
GV-Joystick V2 GV-Joystick V2 facilitates focusing, zooming, panning, tilting of GeoVision and third-party PT, PTZ and Speed Dome cameras on GV-IP Decoder Box or GV-IP Display.
HDMI Cable Use the HDMI cable to connect GV-IP Decoder Box with a HDMI monitor for high-quality display of images.
Length: 150 cm (4.92 ft)
Version: 1.4a
GV-POE Switch GV-POE Switch is designed to provide power along with network connection to IP devices. It is available in various models with different numbers and types of ports.
Power Adapter Contact our sales representatives for the countries and areas supported.

Download

https://www.geovision.com.tw/download/product/GV-IP%20Decoder%20Box%20Optimal
