GV-PDR8800

Categories: ,

Description

8MP H.265 Super Low Lux WDR Pro IR Fixed Rugged IP Dome

AI Deep-Learning IP Camera

The panoramic dome IP camera is an outdoor, network camera that captures 180° horizontal coverage, providing a wide coverage of view for open and large areas with just one camera. It is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. GV-PDR8800 adheres to IK10 and IP67 standards, and can be powered through PoE. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths.

Empowered by deep learning algorithms, AI technology distinguishes human and vehicles from other moving objects. Integrated with GeoVision Video Management Software (VMS), it supports AI perimeter protection, real time alert, events playback and more.

Models

Model GV-PDR8800
Iris Fixed
Focal Length (mm) 1.68mm
Horizontal FOV 180°
Maximum Aperture F/2.0
Image Format 1/2.8″

Key Features

  • AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle)
  • 1/2.8″ progressive scan CMOS sensor
  • Min. illumination at 0.012 lux
  • Triple streams from H.265, H.264 or MJPEG
  • Up to 25 fps at 3840 x 2160
  • Intelligent IR
  • IR distance up to 15 m (50 ft)
  • Day and Night function (with removable IR-cut filter)
  • 180° panoramic view
  • Vandal resistance (IK10 for metal casing)
  • Ingress protection (IP67)
  • DC 12V / PoE (IEEE 802.3af)
  • Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
  • Built-in microphone
  • Wide Dynamic Range Pro (WDR Pro)
  • AI analytics (Line Crossing, Region Entrance, Region Exiting, Advanced Motion Detection, Loitering, People Counting)
  • Tampering alarm
  • 3D noise reduction
  • Motion detection
  • Text overlay
  • Privacy mask
  • 20 languages supported
  • ONVIF (Profile G, Q, S, T) conformant
  • SIP/VoIP Support

Note:

  • All specifications are subject to change without notice.

Overview




Note:

  • All specifications are subject to change without notice.

Accessories

Model No Name Details
GV-Mount430 Pole Mount Bracket Dimensions: 180 x 51.5 x 152.6 mm (7.09″ x 2.03″ x 6.01″)
Weight: 720 g (1.59 lb)
(must be used with GV-Mount211-5)
GV-Mount211-5 Wall Mount Bracket Dimensions: 162 x 124 x 78 mm (6.38″ x 4.88″ x 3.07″)
Weight: 0.53 kg (1.168 lb)
GV-PA191 PoE Adapter Power over Ethernet (PoE) Adapter The GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable.
GV-POE Switch GV-POE Switch is designed to provide power along with network connection to IP devices. It is available in various models with different numbers and types of ports.
Power Adapter Contact our sales representatives for the countries and areas supported.

Packing List

  • GV-PDR8800 Dome
  • Waterproof Rubber Set
  • Screw Kit
  • Hex Key H2.0
  • Download Guide

Note:

  • All specifications are subject to change without notice.
