GV-VMS V17 is a comprehensive video management system that records up to 64 channels of GeoVision and third-party IP devices. The live view and playback layout can be easily adjusted with the intuitive drag-and-drop function. GV-VMS V17 comes with a variety of intelligent video analytics to offer precise monitoring and to reduce the need for manual supervision. The built-in Webcam Server allows users to remotely access live view and recordings from anywhere using Web browsers, mobile app and Remote ViewLog. Compatibility with GeoVision central monitoring systems and support for a wide selection of third-party cameras make GV-VMS a versatile and effective surveillance solution.
Key Features
Fisheye dewarping for GeoVision and 3rd party fisheye cameras
H.265 decoding and smart streaming to reduce file size and bandwidth
Retail video analytics: People Counting, Heat Map
Video analytics: Intrusion Alarm, Crowd Detection, Scene Change Detection, Privacy Mask, Unattended and Missing Object Detection
Advanced video analytics: Face Recognition
Dual stream for monitoring and recording to save CPU usage
Quick Search: Timeline Search, Object Search by Area
Multiple displays for live view and playback on different monitors
E-Map; IO Device Control; PTZ Auto Tracking
GeoVision Dynamic DNS server for providing a domain name if no fixed IP addresses are available
Support for Microsoft SQL and Access data types
Central password management with Windows Active Directory
Support for ONVIF, PSIA, and RTSP protocols
Integration with central monitoring systems: GV-Center V2, GV-Vital Sign Monitor, GV-Dispatch Server, and GV-Control Center
Remote monitoring through Web browsers and mobile devices
Note :
To remotely view from 33 to 64 channels on the GV-Edge Recording Server (Windows version), you will need to purchase an additional license. Currently, GV-Edge Recording Server (Mac version) only supports remote connection with up to 32 channels.
Overview
Note :
To remotely view from 33 to 64 channels on the GV-Edge Recording Server (Windows version), you will need to purchase an additional license. Currently, GV-Edge Recording Server (Mac version) only supports remote connection with up to 32 channels.
Accessories
Model No
Name
Details
GV-IR Remote Control
GV-IR Remote Control allows you to control GV-VMS at the maximum operation distance of 7 m (22.97 ft).
GV-NET I/O Card V3.2
GV-NET/IO card V3.2 provides 4 inputs and 4 relay outputs. It supports both DC and AC output voltages and provides a USB port as well.
GV-COM V3
GV-COM V3 adds 1 RS-485 port to your computer through a USB connector.
GV-IO Box Series
GV-IO Box series provides 4 / 8 / 16 inputs and relay outputs, and supports both DC and AC output voltages, with optional support for Ethernet module and 4E additionally supporting PoE connection.
GV-Joystick V2
GV-Joystick V2 allows you to easily control PTZ cameras. It can be either plugged into the GV-VMS for independent use or connected to GV-Keyboard.
GV-Keyboard V3
GV-Keyboard V3 is used to program and operate the GeoVision surveillance system. You can also connect PTZ cameras directly to the keyboard for PTZ control.
GV-Data Capture
GV‐Data Capture allows the integration of POS systems and the GeoVision surveillance system through cable or network connection.
Video
Upgrading from GV-NVR to GV-VMS
Adding IP Cameras to GV-VMS and Accessing Live View
Creating Live View Layouts
Playing Back, Exporting and Backing up Videos
Setting Up GV Fisheye Cameras
Controlling PTZ Cameras
Heat Map for Motion Intensity and Crowd Management
Setting Up Heat Map
Outdoor Intelligent Motion Detection of GV-VMS
Licensing the GV-VMS Online and Offline
GeoVision GV-VMS – PPTZ Auto Tracking
GeoVision GV-VMS – Creating and Utilizing the 3D E-Map
Note :
To remotely view from 33 to 64 channels on the GV-Edge Recording Server (Windows version), you will need to purchase an additional license. Currently, GV-Edge Recording Server (Mac version) only supports remote connection with up to 32 channels.
